Colorlight A2K LED Media Player $140.00 – $160.00
Colorlight X2s Colorlight Professional LED Display Panel Controller $96.00 El precio original era: $96.00.$70.00El precio actual es: $70.00.
¡Oferta!

ColorLight S2 LED Panel Sending Box

El precio original era: $146.00.El precio actual es: $99.00.

-32%

ColorLight S2 LED Panel Sending Box Features： ·DVI signal input port ·Audio input port with synchronous transmission via Ethernet cable ·Maximum input resolution: 1920*1200 pixels ·Loading capacity: 1.31 million…

Add to Cart
ColorLight S2 LED Panel Sending Box
$146.00 El precio original era: $146.00.$99.00El precio actual es: $99.00.

Free worldwide shipping on all orders over $50

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

ColorLight S2 LED Panel Sending Box
$146.00 El precio original era: $146.00.$99.00El precio actual es: $99.00.

[wpforms id=”1190″ title=”true” description=”Request a call back”]

ColorLight S2 LED Panel Sending Box Features：

·DVI signal input port

·Audio input port with synchronous transmission via Ethernet cable

·Maximum input resolution: 1920*1200 pixels

·Loading capacity: 1.31 million pixels

·Maximum Width: 2560 pixels, Maximum Height: 2560 pixels

·2 Gigabit Ethernet port outputs support screen arbitrary splicing

·Dual USB ports for high speed configuration and easy cascading

·Improved grayscale performance at low brightness

·Wide working voltage with AC 100 ~ 240V

·Compatible with all series of Colorlight receiving cards



ColorLight S2 LED Panel Sending Box Parameters：

Video Source Interface

 Interface Type

DVI

 Input Resolution

1920*1200 pixels

Frame Rate

Standard 60Hz, and auto adjustment

Gigabit Ethernet Outputs

Quantity

2 ports

Net Port Control Area

Each net port is 1280*512 pixels (or equivalent area). 2 net ports are 1280*1024 pixels (or equivalent area)

Single card max width up to 2560 pixels, and 2560 pixels in height

 Transmission Distance

CAT5≤140M；CAT6≤170M；Optical fiber: No limitation

Net Port Cascading

Up-down or left-right cascading defined by user

 Transmission Mode

Frame mode (Gigabit Ethernet) with CRC

Connection equipment

Receiving Card

Compatible with all series of Colorlight receiving card

Peripherals

Multifunction card, optical fiber transceivers, gigabit switcher

Parameters

Size

275*198*44 mm

Input Voltage

AC 100V-240V

Power Consumption

15W

Weight

2.1kg

External interfaces

Configuration Port

USB

Real-time Configuration

Support

Brightness and Chromaticity Adjustment

Support

Smart Detection System

DVI interface detection

Real-time Clock

Includes real-time clock

More functions

Multi-Screen Control

Multiple screens with different sizes can be controlled simultaneously

Background Playing

Support background playing (Extended mode)

Audio Transmission

Support

BER Detection

Ethernet cable quality and malfunction detection



SKU: 6805762441407 Categoría: Etiquetas: ,
