Magnimage LED-750H LED Wall Video Processor

$686.00

Magnimage LED-750H LED Wall Video Processor Features: 1)2 screens mosaic in 1 processor. 4 DVI output ports are divided into 2groups for horizontal mosaic, vertical mosaic, same size…

Add to Cart
Magnimage LED-750H LED Wall Video Processor
$686.00

Free worldwide shipping on all orders over $50

  • 30 days easy returns
  • Order yours before 2.30pm for same day dispatch
Guaranteed Safe Checkout

Magnimage LED-750H LED Wall Video Processor
$686.00

[wpforms id=”1190″ title=”true” description=”Request a call back”]

Magnimage LED-750H LED Wall Video Processor Features:

1)2 screens mosaic in 1 processor. 4 DVI output ports are divided into 2groups for horizontal mosaic, vertical mosaic, same size mosaic and different size mosaic. One single processor up-loads 4,600,000 pixels.
2)4 windows output. On non-mosaic mode, each output is capable of
displaying 4 layers within any size or position.
3)Preview switching：preview switching between 1 image and 3 images.
4)Multiple cascade：machines can be cascaded to realize ultra wide display.
5)Built-in input matrix for seamless switching between 7 inputs
6)EDID management & user-defined output resolution
7)Rotary output
8)LOGO saving& image crop
9)Time and task & graphic card for testing
10)Computer host control
11)Save and load preset & image freezing

Parameter of Magnimage LED-750H LED Wall Video Processor:

Input Indicators
Port Quantity Resolution
DVI 2 1920×1080/60Hz and EDID
DP 1

Displayport 1.1,3840×1080/60Hz、

3840×2160/30Hz and EDID
HDMI 2 1920×1080/60Hz and EDID
Extend Input Indication
Port Quantity Resolution
DVI DVI×1 1920×1080/60Hz and EDID
VGA VGA×1 VESA standard
SDI SDI×1

480i/60Hz    576i/50Hz

720p/60Hz    1080i/60Hz/50Hz
1080p/60Hz/50Hz(3G SDI)
DP 1.1 DP×1、DVI×1

3840×1080/60Hz、

3840×2160/30Hz and EDID
HDMI 1.4 HDMI×1、DVI×1

3840×1080/60Hz、3

840×2160/30Hz and EDID

You can extend 2 x 2K inputs

(VGA, DVI, SDI) or

1 x 4K input (DP1.1, HDMI1.4)
Output Indication
Port Quantity Resolution（single DVI output）
DVI 2×2

1024×768/60Hz

1280×1024/60Hz

1024×768/120Hz

1280×720/60Hz

1440×900/60Hz

1600×1200/60Hz

1600×1200/60Hz- Reduced

1680×1050/60Hz

1920×1080/60Hz

1920×1080/50Hz

2176×1168/60Hz

1920×1200/60Hz

1936×1280/60Hz

2048×1152/60Hz

1024×1280/60Hz

1536×1536/60Hz

1280×720/59.94Hz

1920×1080/59.94Hz

The customize output

resolutionis 3966 for

maximum width or 3541
for maximum height.
Console Specification
Power Supply 100～240VAC，50/60Hz
Consumption 55W
Operating Temperature 0~45℃
Product Dimension 482.6×452×66.75mm
Net Weight 2.6Kg



More pictures of Magnimage LED-750H LED Wall Video Processor：





Download of Magnimage LED-750H LED Wall Video Processor:
Magnimage-LED-750H-LED-Wall-Video-Processor-User-Manual
Magnimage-LED-750H-LED-Wall-Video-Processor-Brief-Software
