Novastar LCB4K LCD multimedia player Features：
- Output：
1x HDMI 2.0 connector
−Adaptive mode: The LCB4K automatically adjusts the playback window resolution according to the EDID of the LCD display.
−Custom mode: The user manually sets the playback window resolution.
1x Stereo audio connector
-The audio sample rate of the internal source isfixed at 48 kHz.
- Control：
1x USB 3.0 (Type A) port
-Allows for USB playback and firmware upgrade over USB, and cascades a sending device for control.
1x USB 2.0 (Type A) port
-Allows for USB playback and firmware upgrade over USB, and cascades a sending device for control.
1x USB 2.0 (Type B) port
-Connects to the control computer for content publishing and screen control
1x Gigabit Ethernet port
-Connects to the control computer or connects to a LAN or public network for content publishing and screen control.
- Performance：
Powerful processing capacity
−Quad-core ARM A55 processor @1.8 GHz
−Support for H.264/H.265 4K@60Hz video decoding
−2 GB of RAM
−32 GB of internal storage
Flawless playback
-Supports playback of 2x 4K, 6x 1080p, 10x 720p, or 20x 360p videos.
- Functionality：
All-round control plans
−Allows users to publish content and control screens from a computer, mobile phone, or tablet.
−Allows users to publish content and control screens from anywhere, anytime.
−Allows users to monitor screens from anywhere, anytime.
Switching between Wi-Fi AP and Wi-Fi STA
−In Wi-Fi AP mode, the user terminal connects to the built-in Wi-Fi hotspot of the LCB4K. The default SSID is “AP+Last 8 digits of SN” and the default password is“12345678”.
−In Wi-Fi STA mode, the user terminal and the LCB4K are connected to the Wi-Fi hotspot of a router.
Synchronous playback across multiple screens(Playback limit: 1x 4K video)
−NTP time synchronization
−GPS time synchronization (The specified 4G module must be installed.)
−RF time synchronization (The specified RF module must be installed.)
Support for 4G/5G modules
-The LCB4K ships without a 4G/5G module. Users have to purchase 4G/5G modules separately if needed. Currently only the 5G networks in China can be accessed.
-Network connection priority: Wired network > WiFi network > 4G/5G network
-When multiple types of networks are available, the LCB4K will choose a signal automatically according to the priority
Download Specification:
Novastar LCB4K LCD multimedia player Specification
