Features of LINSN EB901 LED Screen Signal Distributing Controller:
Designed for multiple screens;
Can be used as a signal hot backup device;
Divide 1 signal into 8 signal from sending card or 2 signal into 4 singal; the two modes can be switched freely;
When using 1 to 8 mode, up to 8 cards can be cascaded(that is 1 to 64)
Independent power supply;
In line with EU standards RoHS.
Parameter of LINSN EB901 LED Display Signal Distributing Controller:
Model |
EB901 |
Input |
RJ45 (1~2 ports) |
Output |
RJ45 (4~8 ports) |
Net weight |
1.04KG |
Length |
357mm |
Width |
173mm |
Height |
45mm |
Input Voltage |
100~240 V AC |
